Connecting systems for Modern Wood Curtain Walls

As a producer of patented connecting systems we develop and produce high-quality products which are distributed worldwide. Not only will our connecting systems convince – but also inspire you with the wide range of applications. The comprehensive service offers you the possibility to find the best, the most efficient and innovative solution for the realisation of your products.

On the following pages you will find our connector systems for modern wood curtain walls. Every connector permits high prefabrication and possesses the CE- and Ü-Marking through European and German certification of standards. Regular external inspection guarantees maximum security for planners, architects, manufacturers and owners.

Are you from the Americas? Follow the link to view our connectors for Wood Curtain Walls on our US website!
With over 30 years of experience inventing connecting solutions for woodworkers, KNAPP® is proud to say, „we supply the world“. While our main headquarters is located in Austria, KNAPP® has been supplying connectors to the United States and Canada for over 20 years. As the demand for invisible connecting solutions grew, we replied by establishing our U.S. branch in 2017 to better serve the needs of our fellow woodworkers. If you live within North, South, or Central America, please visit KNAPPconnectors.com or email info@KNAPPconnectors.com to be connected with the right representative.

RICON® | The connector for main and secondary beam up to 23,4 kN

The main and secondary beam joint connector RICON® consists of two identical connector plates made of steel. An optional lock can be installed to latch the connector. The RICON® is recessed and non-visible, and can be used with timber widths as little as 50 mm. RICON® is available in a single connector set and double connector set for cross joints in six sizes 60, 80, 100, 120, 140 and 160/40. The RICON is also available in stainless steel.

NEW and improved:

  • Better grip on the timber by means of a star-shaped embossing on the backside of the connector plate.
  • Mounting also on intermediate layers up to 26 mm (i.e. OSB).
  • Special coating for increased corrosion resistance for indoor swimming pools, riding halls, stables and farm buildings (tested).
  • Approval for off-centered glass loads up to 700 kg given by an additional reinforcing plate.
  • ETA extension for Hardwood (i.e. oak, larch, beech)
  • Concealed – connectors are recessed and non-visible.
  • Disassembly and reassembly possible if needed.
  • High degree of prefabrication – fast and exact assembly on-site.
  • Universal – connectors can fasten timber to timber, to steel and to concrete components.
  • Unique – can also be used for polygon façades.
  • Slim timber dimension – can be mounted on timber with thickness as little as 50mm and up to 450mm.
  • Labor efficient – no additional screwing or nailing needed when assembled on site.
  • Adjustable – can be adjusted according to joints intervals and construction tolerances.
  • Versatile – can be used for single joint and double joint applications.
  • Flexible – direction of assembly can even be from the outside towards the inside and from down upwards.
  • Safety – fire resistance according to (DIN 4102-2) by 4-sided concealed mounting (R30 ≥ 20 mm, R60 ≥ 40 mm).
  • Neutral – can be used in combination with different exterior profile systems such as RP, Schüco, MBJ, Gutmann, RAICO, Stabalux, … etc.
